CUTCRAFT DRG22T

Self-contained 22-tonne splitter with a 6.5 hp petrol engine.

Available · CC-DRG22T

22t
Splitting force: 6.5hp
Engine power: 24s
Cycle time

The DRG22T is an independent petrol splitter: no tractor, no mains socket. A 6.5 hp four-stroke drives a two-stage pump delivering 22 tonnes, for a full 24-second cycle. 230 kg on a 2.26 m frame.

Who it is for

For households producing several cords a year and for tradespeople working on their customers' land, far from any supply.

In practice

At the far end of a plot or in a garden with no power, it starts and works. The two-stage pump speeds the ram's return: on straight wood, most of the cycle runs at fast speed.

Technical specifications

Splitting

Splitting force: 22t
Cycle time: 24s

Engine

Engine type: 4-stroke petrol
Engine power: 6.5hp

Hydraulics

Pump: Two-stage pump

Dimensions and weight

Dimensions (L × W × H): 2260 × 545 × 610 mm
Weight: 230kg

Gallery

Options

WM1200 — 180 kg hydraulic log lifter
CC-WM1200
Lifts up to 180 kg to table height, with an integrated rotator. It solves the real problem of a day's splitting: it is not the machine that tires, it is the operator doing the lifting.
