CUTCRAFT WoodMax 20T

Cut and split in one pass, four cubic metres an hour.

Available · CC-WM20T

48cm
Maximum log diameter: 20t
Splitting force: 15hp
Engine power

The WoodMax 20T chains cutting and splitting with no manual handling in between: the log enters on the hydraulic infeed, the 50 cm bar cross-cuts it, the 20-tonne splitter splits it and the 3.2 m conveyor stacks it. A 15 hp Kohler engine drives the lot.

Who it is for

For farmers and heavy domestic users who produce their own firewood and sell part of it, without depending on a tractor.

In practice

On rounds up to 48 cm cut at 55 cm, expect four cubic metres an hour with two people. The knife swaps between 4 and 6 way depending on whether you deliver open-fire logs or stove-sized splits.

Technical specifications

Engine

Engine: Kohler
Engine type: Petrol
Engine power: 15hp

Splitting

Splitting force: 20t
Splitting knife: 4 or 6 way
Output: 4cu. m/h

Cutting

Maximum log diameter: 48cm
Cutting length: 55cm
Chainsaw bar: 50cm

Equipment

Infeed conveyor: 2m
Outfeed conveyor: 3.2m
Belt width: 250mm

Dimensions and weight

Dimensions (L × W × H): 250 × 150 × 180 cm
Weight: 520kg

Gallery

Options

4-way splitting knife — 20 t
CC-KN4-20T
Four splits per stroke on medium sections. This is the knife fitted as standard, and the one that suits most open-fire firewood deliveries.
6-way splitting knife — 20 t
CC-KN6-20T
Six splits per stroke, for smaller stove wood. The gain in rate is clear on regular rounds; on knotty timber, 20 tonnes starts to show.
WM1200 — 180 kg hydraulic log lifter
CC-WM1200
Lifts up to 180 kg to table height, with an integrated rotator. It solves the real problem of a day's splitting: it is not the machine that tires, it is the operator doing the lifting.
